Metabo MAG 32 [10/36] Cleaning maintenance

ENGLISH

ENG

the mains plug, the magnet loses its holding

power.

Tools with a taper shank MK2 can be used directly

in the female taper of the drill spindle (11).

Driving out

the tool:

Insert the removal tool (10) - with the sloping edge

against the tool - in the slot (9) on the machine

neck. If the removal tool cannot be inserted

through the drill spindle, you should turn the drill

spindle (11) slightly by hand. Drive out the tool by

knocking lightly on the removal tool with a

hammer. (10)

Special notes on tools with

Weldon shank 19 mm:

For MAG 50: First insert the industrial attachment

6.26602 (see chapter 9 Accessories).

When inserting the attachment, ensure that

the side pin of the industrial attachment

engages with the anti-twist device (23).

Then connect the hose from the c

ooling lubrica-

tion unit to the connecting piece on the industrial

attachment

6.26602.

Inserting the

tool

- Insert the centring pin (of an appropriate length)

into the tool.

- Insert the tool in the tool holder (22) so that both

surfaces (on the cylindrical part of the tool) are

located at the positions of the threaded pins (21).

- Guide the tool upwards as far as it will go

(against the pressure of the integral spring) and

tighten the threaded pins (21) using the Allen key.

Removing

the tool

- Release the two threaded pins (21).

Perform regular maintenance work, cleaning and

lubrication.

Remove the mains plug from the socket before

carrying out any settings, maintenance or repairs.

Caution! When you unplug the mains plug, the

magnet loses its holding power.

For lubricating the rack and pinion that moves the

slide plate (14) up and down, a few drops of oil

should be applied occasionally to the rack.

Coat the sliding surfaces of the slide plate (14) with

multi-purpose grease.

Backlash of the slide plate

The backlash of the side plate is set ex works.

The side plate (14) must be adjusted so that it can

still be moved freely up and down (when the

driving unit is installed), and so that it will remain in

any position without the weight of the driving unit

pulling it down.

If necessary, you can adjust the backlash of the

slide plate (14) using the three threaded pins (7):

release the counternuts, tighten the threaded pins

and fasten the counternuts again.

Electronic restart protection (for preventing

accidental restarting)

If, when the driving unit is switched on,

a) the magnet is switched off or

b) the power supply is interrupted,

the driving unit comes to a standstill.

If the magnet is then reactivated or the power

supply restored, the driving unit will not restart

automatically for safety reasons (electronic restart

protection). Switch on the driving unit again at the

switch (16) .
