Metabo MAG 32 [7/36] Functional description

ENGLISH

ENG

Do not expose the machine to rain and do not use

in wet or potentially explosive rooms.

Disconnect the mains plug from the plug socket

before performing any adjustments or mainte-

nance on the machine. Caution! When you unplug

the mains plug, the magnet loses its holding

power.

If (after use) the magnetic drill stand is placed on a

material with low heat-dissipation characteristics

for a long period (e.g. plastic), the magnet must not

be switched on because this could lead to over-

heating of the magnetic coils.

Follow the instructions for lubrication and tool

replacement.

Keep the handles dry, clean and free of oil and

grease.

Caution! The use of other tools and accessories

can result in a risk of injury.

Use the

handle (4) on the magnetic drill stand

when transporting the machine.

Always wear a safety harness when

working on scaffolds.

Wear ear protectors.

Wear protective goggles.

Danger - electrical voltage.

Danger - magnetic field.

Persons with pacemakers prohibited.

Symbols on the tool:

V............... volts

A............... amperes

W.............. watt

Hz............. hertz

.../min....... revolutions per minute

~...............alternating current

.............no load speed

See page 3 (please unfold).

1Securing strap

2 Ratchet on securing strap

3 Two holding points

4Handle

5 Container for cooling lubrication unit

6 Supply cock on cooling lubrication unit

7 Threaded pins for adjusting backlash of the

side plate

8 Thumbwheel (1st /2nd gear) *

9 Slot in machine neck for driving out tools *

10 Removal tool *

11 Drill spindle with tool attachment (MK 2) *

12 Setting wheel (speed adjustment) *

13 Electronic signal indicator*

14 Slide plate

15 Lever for moving driving unit up and down

16 Switch (switching on driving unit)

17 Switch (switching off driving unit)

18 Switch (switching on/off magnet)

19 Switch (direction of rotation) *

20 Magnet block/Magnet

21 Tool holder threaded pins*

22 Tool holder (Weldon, 19 mm) *

23 Anti-twist device*

* depending on fittings/model

Before plugging in, check that the rated

mains voltage and mains frequency, as

stated on the rating label, match with your power

supply.

Check the machine for possible damage:

Before using the machine, you must carefully

check protective devices or slightly damaged

components to ensure they are operating perfectly

and as intended. Check that moving parts are in

perfect working order and do not jam and check

whether parts are damaged. All parts must be

correctly installed and fulfil all conditions neces-

sary to ensure the perfect operation of the

machine. Damaged protective devices and parts

must be repaired or replaced according to specifi-

cations by an authorised specialist workshop.

5.1 Power-Supply Connection

The machine is in protection class I and must

therefore only be connected to sockets earthed

according to specifications.

Regularly check the power cable on the power tool

and have it repaired by an approved expert if

damaged.

If an extension cord is needed, it must be a three-

core lead with a protective (earth) contactor that is

properly connected to both the plug and the

coupler of the cord.

4 Functional Description

5 Initial Operation
