Push the connector (12) into the suction hose
(10) and tighten the hose clamp to secure.
Push the suction hose (10) onto the extractor
connection piece on the wood-processing
machine.
7 Initial Use
For operation, the chip extractor re-quires a
mains voltage of 230 V ~ 50 Hz and a suitable
extension cable with an earth conductor
(three-core). The chip extractor may only be
connected to sockets which have been earthed
in compliance with regulations.
Before putting the chip extractor into use, the
suction hose must be connected to the wood-
processing machine as per instructions.
Fit the extension cable to the plug in the
combined switch-plug fitting (4).
Switch in position Chip extractor
0off
Ion
8 Maintenance
Always remove the plug from the mains socket
before undertaking any maintenance task. If
extraction performance drops off and before
every chip bag change, the filter must be
cleaned by tapping it by hand. This causes the
fine sawdust which collects in the fabric of the
filter (1) to fall into the chip back (11), thus
allowing the filter (1) to remain free for the
passage of air. The filter should be cleaned
after every use, but without removing the filter.
Only remove the chip bag once the dust has
had time to settle and the fan impeller has
come to a halt.
In addition, a monthly dust-test should be
carried out by an appropriately instructed
person to check:
– for damage to the filter (1)
– that the housing is tight and that the seal for
the chip bag (11) is intact
– that the electrical equipment is in good
condition (combined switch-plug fitting (4),
extension cable).
Under no circumstances may damaged
filters (1) and chip bags (11) be returned to
use.
9 Accessories
metabo offers a wide range of accessories for
the chip extractor. For this reason you should
use only original
metabo accessories to get the best
out of your appliance. You will find an overview
of accessories on page 4 and also in
metabo’s General Catalogue.
4
15
ENGLISH
