ED12-321A Indoor Units
Installation Manual 165
4
60 class25 class 35/50 class
O.D. 12.7 mmO.D. 9.5 mm O.D. 15.9 mm
O.D. 6.4 mm
Model
Max. allowable length
Max. allowable height
Additional refrigerant required
for refrigerant pipe exceeding
10 m in length.
X
Y
Z
Gas pipe
Liquid pipe
* See the installation manual
supplied with the Multi
outdoor unit.
* Be sure to add the proper amount of additional refrigerant.
Failure to do so may result in reduced performance.
Ceiling mounting
Wall mounting
40
22
35
40~45
1,050
980
55
50
230138
490
Rear side piping hole
80 mm
Right side piping hole 80 mm
55
40
40
Top side piping hole
65 mm
Determine the position of the
feed-through hole so that the
local piping is placed in a
downward sloping direction.
Connection position
Drain pipe
Gas pipe
Liquid pipe
55
40
1,050
800
162
102 26
150
255
490
30
97 48
40
40
1
More than 170
Ceiling
Wall
Wall
Floor
Ceiling
Wall
Wall
Wall
Floor
Floor
Rear side drain hose hole 40 mm
Rear side piping hole 65 mm
Under side piping hole 80 mm
55
1
Local drain pipe
Drain hose
Right side
piping hole
65 mm
35
With a Multi indoor unit,
install as described in the
installation manual supplied
with the Multi outdoor unit.
