Indoor Units ED12-321A
4 Features
2. Indoor Units
2.1 Features
03RAGA-39
Energy Saving
High COP
Comfortable Air Flow
Wide-Angle louvres
(Auto swing right & left)
Healthy & Clean functions
Photocatalytic Deodorizing Filter
Air Purifying Filter
Pair / Multi Compatible Indoor Unit
< FLK(X)50/60AVMA >
Features
03RAGB-11
Energy Saving
High COP
Intelligent Eye
New Flat Panel
Their sleek appearance coordinates so
easily with any interior decor
Comfort, Improved Air flow &
Easy to clean
Comfortable Functions
Home Leave Operation
Indoor Unit Silent Operation
Healthy & Clean Functions
Photocatalytic Deodorizing Function
Same Indoor Unit for Pair / Multi
< FTK(X)E25/35B >
Features
< FTK(X)D50/60/71B >
