Capacity Tables ED12-321A
38 SUPER MULTI NX B-Series Cooling Only
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
6.0+7.1 22 8.23 2.27 8.73 2.52 9.24 2.56 9.49 2.58 10.25 2.63 10.76 2.65
25 7.92 2.67 8.43 2.72 8.93 2.76 9.18 2.78 9.94 2.84 10.45 2.87
32 7.49 2.95 8.00 3.03 8.50 3.09 8.75 3.12 9.51 3.20 10.02 3.26
35 7.31 3.09 7.81 3.17 8.32 3.25
8.57 3.29 9.33 3.38 9.83 3.44
40 7.00 3.33 7.50 3.44 8.01 3.53 8.26 3.58 9.02 3.70 9.53 3.77
43 6.81 3.50 7.32 3.60 7.83 3.67 8.08 3.67 8.81 3.67 9.28 3.67
46 6.52 3.18 6.94 3.18 7.37 3.18 7.56 3.18 8.18 3.18 8.59 3.18
2.5+2.5+2.5 22 7.311.737.761.928.201.968.431.979.102.009.552.02
25 7.03 2.04 7.48 2.07 7.93 2.11 8.16 2.12 8.83 2.16 9.28 2.19
32 6.65 2.25 7.10 2.31 7.55 2.36 7.77 2.38 8.45 2.44 8.90 2.49
35 6.49 2.36 6.94 2.42 7.39 2.48
7.61 2.51 8.28 2.58 8.73 2.62
40 6.21 2.54 6.66 2.62 7.11 2.70 7.34 2.73 8.01 2.82 8.46 2.87
43 6.05 2.67 6.50 2.75 6.95 2.83 7.17 2.87 7.85 2.97 8.30 3.03
46 5.89 2.80 6.34 2.90 6.78 2.99 7.01 3.04 7.68 3.17 8.10 3.18
2.5+2.5+3.5 22 7.461.827.922.038.382.078.612.089.292.129.752.14
25 7.18 2.15 7.64 2.19 8.10 2.22 8.33 2.24 9.02 2.29 9.47 2.31
32 6.79 2.38 7.25 2.44 7.71 2.49 7.94 2.51 8.63 2.58 9.08 2.63
35 6.62 2.49 7.08 2.55 7.54 2.62
7.77 2.65 8.46 2.72 8.92 2.77
40 6.34 2.68 6.80 2.77 7.26 2.85 7.49 2.88 8.18 2.98 8.64 3.03
43 6.18 2.82 6.64 2.90 7.09 2.99 7.32 3.03 8.01 3.14 8.47 3.20
46 6.01 2.95 6.47 3.06 6.93 3.16 7.15 3.18 7.77 3.18 8.18 3.18
2.5+2.5+5.0 22 7.85 1.85 8.34 2.05 8.82 2.09 9.06 2.10 9.78 2.14 10.27 2.16
25 7.56 2.17 8.04 2.22 8.53 2.25 8.77 2.26 9.49 2.31 9.97 2.34
32 7.15 2.40 7.63 2.47 8.11 2.52 8.36 2.54 9.08 2.61 9.56 2.66
35 6.97 2.52 7.46 2.58 7.94 2.65
8.18 2.68 8.90 2.75 9.39 2.80
40 6.68 2.71 7.16 2.80 7.65 2.88 7.89 2.91 8.61 3.01 9.09 3.07
43 6.50 2.85 6.99 2.93 7.47 3.02 7.71 3.06 8.43 3.17 8.92 3.24
46 6.33 2.98 6.81 3.10 7.28 3.18 7.50 3.18 8.15 3.18 8.57 3.18
2.5+2.5+6.0 22 7.99 1.91 8.48 2.13 8.97 2.17 9.22 2.18 9.95 2.22 10.44 2.24
25 7.69 2.25 8.18 2.30 8.67 2.33 8.92 2.35 9.65 2.40 10.14 2.42
32 7.27 2.49 7.76 2.56 8.25 2.61 8.50 2.64 9.24 2.71 9.73 2.76
35 7.09 2.61 7.58 2.68 8.07 2.75
8.32 2.78 9.06 2.86 9.55 2.90
40 6.79 2.81 7.28 2.90 7.78 2.99 8.02 3.02 8.76 3.13 9.25 3.18
43 6.61 2.96 7.11 3.04 7.60 3.13 7.84 3.18 8.58 3.29 9.07 3.36
46 6.44 3.10 6.92 3.18 7.37 3.18 7.59 3.18 8.24 3.18 8.66 3.18
2.5+2.5+7.1 22 8.18 2.02 8.68 2.25 9.19 2.28 9.44 2.30 10.19 2.34 10.69 2.36
25 7.87 2.38 8.38 2.42 8.88 2.46 9.13 2.48 9.89 2.53 10.39 2.56
32 7.45 2.63 7.95 2.70 8.45 2.75 8.70 2.78 9.46 2.85 9.96 2.91
35 7.26 2.75 7.77 2.82 8.27 2.90
8.52 2.93 9.27 3.01 9.78 3.06
40 6.96 2.96 7.46 3.06 7.96 3.15 8.21 3.19 8.97 3.29 9.47 3.36
43 6.77 3.12 7.28 3.21 7.78 3.30 8.03 3.35 8.79 3.47 9.29 3.54
46 6.58 3.18 7.05 3.18 7.51 3.18 7.74 3.18 8.38 3.18 8.80 3.18
2.5+3.5+3.5 22 7.67 1.93 8.14 2.15 8.61 2.19 8.85 2.20 9.56 2.24 10.03 2.26
25 7.38 2.28 7.86 2.32 8.33 2.36 8.56 2.37 9.27 2.42 9.74 2.45
32 6.98 2.52 7.45 2.59 7.93 2.64 8.16 2.67 8.87 2.74 9.34 2.79
35 6.81 2.64 7.28 2.71 7.75 2.78
7.99 2.81 8.70 2.89 9.17 2.94
40 6.52 2.84 7.00 2.94 7.47 3.02 7.70 3.05 8.41 3.16 8.88 3.22
43 6.35 2.99 6.82 3.07 7.30 3.17 7.53 3.21 8.24 3.33 8.71 3.40
46 6.18 3.13 6.64 3.18 7.08 3.18 7.30 3.18 7.93 3.18 8.34 3.18
2.5+3.5+5.0 22 7.99 1.94 8.48 2.16 8.97 2.20 9.22 2.21 9.95 2.25 10.44 2.27
25 7.69 2.29 8.18 2.33 8.67 2.37 8.92 2.38 9.65 2.43 10.14 2.46
32 7.27 2.53 7.76 2.59 8.25 2.65 8.50 2.68 9.24 2.75 9.73 2.80
35 7.09 2.65 7.58 2.72 8.07 2.79
8.32 2.82 9.06 2.90 9.55 2.95
40 6.79 2.85 7.28 2.95 7.78 3.03 8.02 3.07 8.76 3.17 9.25 3.23
43 6.61 3.00 7.11 3.09 7.60 3.18 7.84 3.22 8.58 3.34 9.07 3.41
46 6.44 3.14 6.91 3.18 7.37 3.18 7.58 3.18 8.23 3.18 8.65 3.18
2.5+3.5+6.0 22 8.16 1.98 8.66 2.20 9.16 2.24 9.41 2.25 10.17 2.29 10.67 2.31
25 7.86 2.33 8.36 2.37 8.86 2.41 9.11 2.42 9.86 2.47 10.36 2.50
32 7.43 2.58 7.93 2.64 8.43 2.70 8.68 2.72 9.44 2.79 9.94 2.85
35 7.25 2.69 7.75 2.76 8.25 2.84
8.50 2.87 9.25 2.95 9.75 3.00
40 6.94 2.90 7.44 3.00 7.94 3.08 8.20 3.12 8.95 3.23 9.45 3.29
43 6.76 3.06 7.26 3.14 7.76 3.23 8.01 3.28 8.76 3.40 9.27 3.47
46 6.57 3.18 7.05 3.18 7.51 3.18 7.73 3.18 8.38 3.18 8.79 3.18
