5-18
Chapter 5: BIOS Setup
5.5.7 Onboard LAN Configuration
Onboard I210 LAN Configuration
Intel I210 LAN1
LAN Enable [Enabled]
Allows you to enable or disable the Intel LAN.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set
LAN Enable
to
[Enabled]
.
Intel LAN ROM Type [PXE]
Allows you to select the Intel LAN ROM type.
Configuration options: [Disabled] [PXE] [iSCSI]
Due to Intel
®
limitations, both Intel LAN ROM Type options should be the same when
[PXE]
or
[iSCSI]
is selected.
Intel I210 LAN2-4
LAN Enable [Enabled]
Allows you to enable or disable the Intel LAN.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set Intel
LAN Enable
to
[Enabled]
.
Intel LAN ROM Type [Disabled]
Allows you to select the Intel LAN ROM type.
Configuration options: [Disabled] [PXE] [iSCSI]
Due to Intel
®
limitations, both Intel LAN ROM Type options should be the same when
[PXE]
or
[iSCSI]
is selected.
