Asus RS100-E10-PI2 [21/168] Reinstalling the chassis cover

2-3

ASUS RS100-E10-PI2

2.1.2 Reinstalling the chassis cover

To reinstall the chassis cover:

1. Position the cover on top of the chassis with the hooks aligned to the side tabs of the

chassis.

Side tabs
