Asus RS100-E10-PI2 [30/168] Removing a dimm from a single clip dimm socket

Chapter 2: Hardware Information

2-12

1. Press the retaining clip outward to

unlock the DIMM.

2. Remove the DIMM from the socket.

Removing a DIMM from a single clip DIMM socket

SupporttheDIMMlightlywithyourngerswhenpressingtheretainingclips.TheDIMM

might get damaged when it pops out with extra force.
