ASUS TS100-E9-PI4 6-9
6. Select Yes to accept the terms of the License Agreement and continue the process.
7. Read the Readme File Information and press Next to continue the installation.
8. Toggle Yes, I want to restart the computer now and click Finish to complete the
setup process.
