Chapter 1: Product Introduction
1-6
1.5 Rear panel features
The rear panel includes a slot for the motherboard rear I/O ports, expansion slots, a vent for
the system fan, and the power supply module.
500W Bronze
Single power supply
Power connector
Expansion slots
PCI-E latch
USB 2.0 ports
Serial port
VGA port
Gigabit LAN port 1
120 mm x 120 mm
system fan vents
PS/2 keyboard /
mouse port
Gigabit LAN port 2
USB 3.0 ports
