Asus TS100-E9-PI4 [27/138] System memory

2-9

ASUS TS100-E9-PI4

2.3 System memory

2.3.1 Overview

ThemotherboardcomeswithfourDoubleDataRate4(DDR4)DualInlineMemoryModules

(DIMM)sockets.

A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT

install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.

ThegureillustratesthelocationoftheDDR4DIMMsockets:

2.3.2 Memory Configurations

YoumayinstallunbufferedDDR4DIMMsintotheDIMMsocketsusingthememory

congurationsinthissection.

Memory Configuration

DIMM

Slot Per

Channel

DIMM

Populated per

Channel

DIMM Type Speed Rank per DIMM

2 1 Unbuffered DDR4 2133 SingleRank,DualRank

2 2 Unbuffered DDR4 2133 SingleRank,DualRank

• AlwaysinstallDIMMswiththesameCASlatency.Foroptimumcompatibility,itis

recommended that you obtain memory modules from the same vendor.

• StartinstallingtheDIMMsinslotsA2andB2(Blue).
