ASUS TS100-E9-PI4
1-5
1.4 Front panel features
The TS100-E9-PI4 Pedestal server features a simple yet stylish front panel design. The
power and reset buttons, LED indicators, optical drive, and USB ports are all conveniently
located at the fron panel for easy access.
• Refer to the Front panel LEDs section for the LED descriptions.
• The Microphone and Headphone port are available if you install an optional Add-on
Audio card into your system.
Optical Drive (Optional)
Empty 5.25-inch bay
HDD access LED
Reset button
Microphone port
Headphone port
Power button
USB 2.0 ports
USB 3.0 ports
Power LED
