Asus TS100-E9-PI4 [28/138] Installing a dimm on a single clip dimm socket

Chapter 2: Hardware Information

2-10

2.3.3 Installing a DIMM on a single clip DIMM socket

3. HoldtheDIMMbybothofitsends

theninserttheDIMMverticallyintothe

socket.Applyforcetobothendsofthe

DIMMsimultaneouslyuntiltheretaining

clipsnapsbackintoplaceandthe

DIMMcannotbepushedinanyfurther

toensurepropersittingoftheDIMM.

Locked Retaining Clip

1. UnlockaDIMMsocketbypressingthe

retaining clip outward.

2. AlignaDIMMonthesocketsuchthat

thenotchontheDIMMmatchesthe

DIMMslotkeyonthesocket.

Unlocked retaining clip

DIMM notch

DIMM slot key

1. Press the retaining clip outward to

unlocktheDIMM.

2. RemovetheDIMMfromthesocket.

Removing a DIMM from a single clip DIMM socket

• ToinstalltwoormoreDIMMs,refertotheuserguidebundledinthemotherboard

package.

• Refertotheuserguideforqualiedvendorlistsofthememorymodules.

SupporttheDIMMlightlywithyourngerswhenpressingtheretainingclips.TheDIMM

mightgetdamagedwhenitipsoutwithextraforce.

AlwaysinserttheDIMMintothesocketverticallytopreventDIMMnotchdamage.

ADIMMiskeyedwithanotchsothatittsinonlyonedirection.DONOTforceaDIMMinto

asocketinthewrongdirectiontoavoiddamagingtheDIMM.
