Asus TS100-E9-PI4 [14/138] Systemspecifications
![Asus TS100-E9-PI4 [14/138] Systemspecifications](/views2/1771520/page14/bge.png)
Chapter 1: Product Introduction
1-4
* Specications are subject to change without notice.
OS Support
Windows
®
Server 2012
Windows
®
Server 2012 R2
RedHat
®
Enterprise Linux
SuSE
®
Linux Enterprise Server
CentOS
VMware
Citrix XenServer
* Visit http://www.asus.com/ for the latest OS support.
Anti-virus Software
Optional Anti-Virus CD Pack
Management
Solution
Software
ASUS ASWM Enterprise
Dimension (HH x WW x DD)
436.8 mm x 200 mm x 478.8 mm
Net Weight Kg (CPU, DRAM &
HDD not inclu ded)
15 Kg
Power Supply
500W Bronze 80PLUS Single Power Supply
Power Rating
100–240V, 10A-6A, 50-60Hz, Class I
Environment
Operating temperature: 10°C–35°C
Non-operating temperature: -40°C–70°C
Non-operating humidity: 20%–90% (Non-condensing)
Systemspecications
