ASUS TS100-E9-PI4
4-31
Package C state demotion [Disabled]
AllowsyoutoenableordisablethePackageCstatedemotion.
Congurationoptions:[Disabled][Enabled]
Package C state undemotion [Disabled]
AllowsyoutoenableordisablethePackageCstateundemotion.
Congurationoptions:[Disabled][Enabled]
CState Pre-Wake [Enabled]
AllowsyoutoenableordisabletheCStatePre-Wake.Selecting
[Disabled]
will set bit 30 of
POWER_CTLMSR(0x1FC)to1todisabletheCStatePre-Wake.
Congurationoptions:[Disabled][Enabled]
Package C State limit [AUTO]
AllowsyousetthePackageCStatelimit.
Congurationoptions:[C0/C1][C2][C3]C6][C7][C7s][C8][AUTO]
CFG lock [Enabled]
AllowsyoutocongureMSR0xE2[15],CFGlockbit.
Congurationoptions:[Disabled][Enabled]
Intel TXT(LT) Support [Disabled]
AllowsyoutoenableordisabletheIntel(R)TXT(LT)support.
Congurationoptions:[Disabled][Enabled]
