Daikin RKS60E2V1B [146/258] Electrical box temperature rise
![Daikin FTXS50EV1B [146/258] Electrical box temperature rise](/views2/1776858/page146/bg92.png)
SiBE04-609 Troubleshooting
Service Diagnosis 137
4.17 Electrical Box Temperature Rise
Remote
Controller
Display
L3
Method of
Malfunction
Detection
An electrical box temperature rise is detected by checking the radiation fin thermistor with the
compressor off.
Malfunction
Decision
Conditions
With the compressor off, the radiation fin temperature is above 95°C. (Reset is made when the
temperature drops below 80°C.)
Supposed
Causes
Fin temperature rise due to defective outdoor unit fan
Fin temperature rise due to short-circuit
Fin thermistor defective
Connector in poor contact
Outdoor unit PCB defective
