Specifications SiBE04-609
8 Specifications
1. Specifications
1.1 Cooling Only
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS50D2V1W FTKS50D2V1L
Outdoor Units RKS50E2V1B RKS50E2V1B
Capacity
Rated (Min.~Max.)
kW 5.0 (2.0~5.2) 5.0 (2.0~5.2)
Btu/h 17,100 (6,800~17,700) 17,100 (6,800~17,700)
kcal/h 4,300 (1,720~4,470) 4,300 (1,720~4,470)
Moisture Removal L/h 2.6 2.6
Running Current (Rated) A 7.3 7.3
Power Consumption
Rated (Min.~Max.)
W 1,650 (500~1,820) 1,650 (500~1,820)
Power Factor % 98.3 98.3
COP (Rated) W/W 3.03 (4.00~2.86) 3.03 (4.00~2.86)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Units FTKS50D2V1W FTKS50D2V1L
Front Panel Color White Silver Line
Air Flow Rate
m³/min
(cfm)
H 11.4 (402) 11.4 (402)
M 9.3 (328) 9.3 (328)
L 7.1 (251) 7.1 (251)
SL 6.2 (219) 6.2 (219)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.21 0.21
Power Consumption (Rated) W 48 48
Power Factor % 99.4 99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/M/L/SL dBA 46 / 41 / 35 / 32 46 / 41 / 35 / 32
Sound Power dBA 62 62
Outdoor Units RKS50E2V1B RKS50E2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Type R-410A R-410A
Charge kg 1.50 1.50
Air Flow Rate
m³/min
(cfm)
HH 50.9 (1,798) 50.9 (1,798)
H 48.9 (1,727) 48.9 (1,727)
L 41.7 (1,473) 41.7 (1,473)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.09 7.09
Power Consumption (Rated) W 1,602 1,602
Power Factor % 98.2 98.2
Starting Current A 7.3 7.3
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390 797×960×390
Weight kg 47 47
Gross Weight kg 52 52
Operation
Sound
H / L dBA 47 / 44 47 / 44
Sound Power H dBA 61 61
Drawing No. 3D051812 3D051813
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
