Daikin RKS60E2V1B [18/258] Hz 230v
![Daikin FTXS60EV1B [18/258] Hz 230v](/views2/1776858/page18/bg12.png)
SiBE04-609 Specifications
Specifications 9
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS50EV1B FTKS60EV1B
Outdoor Units RKS50E2V1B RKS60E2V1B
Capacity
Rated (Min.~Max.)
kW 5.0 (2.0~6.0) 6.0 (2.0~6.7)
Btu/h 17,100 (6,800~20,500) 20,500 (6,800~22,900)
kcal/h 4,300 (1,720~5,160) 5,160 (1,720~5,760)
Moisture Removal L/h 2.9 3.9
Running Current (Rated) A 6.9 8.8
Power Consumption
Rated (Min.~Max.)
W 1,550 (500~2,080) 1,990 (500~2,400)
Power Factor % 97.7 98.3
COP (Rated) W/W 3.23 (4.00~2.88) 3.02 (4.00~2.79)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Units FTKS50EV1B FTKS60EV1B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 14.7 (519) 16.2 (572)
M 12.4 (438) 13.6 (480)
L 10.3 (364) 11.4 (402)
SL 9.5 (335) 10.2 (360)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15 0.18
Power Consumption (Rated) W 34 40
Power Factor % 98.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 43 / 39 / 34 / 31 45 / 41 / 36 / 33
Sound Power dBA 59 61
Outdoor Units RKS50E2V1B RKS60E2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Type R-410A R-410A
Charge kg 1.50 1.50
Air Flow Rate
m³/min
(cfm)
HH 50.9 (1,798) 54.2 (1,914)
H 48.9 (1,727) 50.9 (1,798)
L 41.7 (1,473) 45.0 (1,589)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 6.75 8.62
Power Consumption (Rated) W 1,516 1,950
Power Factor % 97.6 98.4
Starting Current A 6.9 8.8
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390 797×960×390
Weight kg 47 47
Gross Weight kg 52 52
Operation
Sound
H / L dBA 47 / 44 49 / 46
Sound Power H dBA 61 63
Drawing No. 3D051643 3D051644
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
