Specifications SiBE04-609
14 Specifications
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTXS71EV1B
Outdoor Units
RXS71E2V1B
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 7.0 (4.0~8.3) 8.1 (4.0~10.0)
Btu/h 23,900 (13,600~28,300) 27,600 (13,600~34,100)
kcal/h 6,020 (3,440~7,140) 6,960 (3,440~8,600)
Moisture Removal L/h 4.5 —
Running Current
Rated
A 10.9 11.0
Power Consumption
Rated (Min.~Max.)
W 2,480 (1,080~3,580) 2,520 (870~3,780)
Power Factor % 98.9 99.6
COP
Rated (Min.~Max.)
W/W 2.82 (3.70~2.32) 3.21 (4.60~2.65)
EER
Rated (Min.~Max.)
kcal/
h·W
——
Piping
Connections
Liquid mm φ 6.4
Gas mm φ15.9
Drain mm φ18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FTXS71EV1B
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 17.4 (614) 19.7 (695)
M 14.6 (515) 16.6 (586)
L 11.6 (409) 13.5 (477)
SL 10.6 (374) 12.1 (427)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.20 0.22
Power Consumption (Rated) W 45 50
Power Factor % 97.8 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46 / 42 / 37 / 34 46 / 42 / 37 / 34
Sound Power dBA 63 63
Outdoor Unit RXS71E2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant
Oil
Model FVC50K
Charge L 0.75
Refrigerant
Model R-410A
Charge kg 1.70
Air Flow Rate m³/min (cfm)
HH 59.4 (2,097) —
H 59.4 (2,097) 52.2 (1,843)
L 46.3 (1,634) 52.2 (1,843)
Fan
Type Propeller
Motor Output W 53
Running Current (Rated) A 10.70 10.78
Power Consumption (Rated) W 2,435 2,470
Power Factor (Rated) % 98.9 99.6
Starting Current A 11.0
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390
Weight kg 56
Gross Weight kg 61
Operation
Sound
H/L dBA 53 / 49 52 / 49
Sound Power H dBA 66 66
Drawing No. 3D052803
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
