Specifications SiBE04-609
10 Specifications
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS71EV1B
Outdoor Units RKS71E2V1B
Capacity
Rated (Min.~Max.)
kW 7.0 (4.0~8.3)
Btu/h 23,900 (13,600~28,300)
kcal/h 6,020 (3,440~7,140)
Moisture Removal L/h 4.5
Running Current (Rated) A 10.9
Power Consumption
Rated (Min.~Max.)
W 2,480 (1,080~3,580)
Power Factor % 98.9
COP (Rated) W/W 2.82 (3.70~2.32)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ15.9
Drain mm φ18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Units FTKS71EV1B
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 17.4 (614)
M 14.6 (515)
L 11.6 (409)
SL 10.6 (374)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.20
Power Consumption (Rated) W 45
Power Factor % 97.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46 / 42 / 37 / 34
Sound Power dBA 63
Outdoor Units RKS71E2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant
Oil
Type FVC50K
Charge L 0.75
Refrigerant
Type R-410A
Charge kg 1.70
Air Flow Rate
m³/min
(cfm)
HH 59.4 (2,097)
H 59.4 (2,097)
L 46.3 (1,634)
Fan
Type Propeller
Motor Output W 53
Running Current (Rated) A 10.70
Power Consumption (Rated) W 2,435
Power Factor % 98.9
Starting Current A 10.9
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390
Weight kg 55
Gross Weight kg 61
Operation
Sound
H / L dBA 53 / 49
Sound Power H dBA 66
Drawing No. 3D052804
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
