Specifications SiBE04-609
16 Specifications
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTYN50EV1B FTYN60EV1B
Outdoor Units
RYN50E2V1B RYN60E2V1B
Cooling Heating Cooling Heating
Capacity
Rated
kW 5.0 5.8 6.0 7.0
Btu/h 17,100 19,800 20,500 23,900
kcal/h 4,300 4,990 5,160 6,020
Moisture Removal L/h 2.9 — 3.9 —
Running Current
Rated
A 6.9 7.1 8.8 9.0
Power Consumption
Rated
W 1,550 1,600 1,990 2,040
Power Factor % 97.7 98.0 98.3 98.6
COP
Rated
W/W 3.23 3.63 3.02 3.43
EER
Rated (Min.~Max.)
kcal/
h·W
————
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTYN50EV1B FTYN60EV1B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 14.7 (519) 16.1 (569) 16.2 (572) 17.4 (614)
M 12.4 (438) 13.9 (491) 13.6 (480) 15.1 (533)
L 10.3 (364) 11.5 (406) 11.4 (402) 12.7 (448)
SL————
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15 0.16 0.18 0.20
Power Consumption (Rated) W 34 36 40 45
Power Factor % 98.6 97.8 96.6 97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 43 / — / 34 / — 42 / — / 33 / — 45 / — / 36 / — 44 / — / 35 / —
Sound Power dBA 59 58 61 60
Outdoor Unit RYN50E2V1B RYN60E2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Model R-410A R-410A
Charge kg 1.50 1.50
Air Flow Rate m³/min (cfm)
HH 50.9 (1,798) — 54.2 (1,914) —
H 48.9 (1,727) 45.0 (1,589) 50.9 (1,798) 46.3 (1,635)
L 41.7 (1,473) 45.0 (1,589) 45.0 (1,589) 46.3 (1,635)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 6.75 6.94 8.62 8.80
Power Consumption (Rated) W 1,516 1,564 1,950 1,995
Power Factor (Rated) % 97.6 98.0 98.4 98.6
Starting Current A 7.1 9.0
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390 797×960×390
Weight kg 48 48
Gross Weight kg 53 53
Operation
Sound
H/L dBA 47 / — 48 / — 49 / — 49 / —
Sound Power H dBA 61 62 63 63
Drawing No. 3D051641 3D051642
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
