Outdoor Unit SiBE04-609
224 Removal Procedure
2.1.7 Removal of the Electronic Expansion Valve
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1
Remove the electronic
expansion valve coil.
In case of 50/60 class heat
pump models.
In case of 50/60 class
cooling only models and
71 class.
2
Remove the sheets of
putty.
The illustration is for 71 class
as representative.
