SiBE04-705 Indoor Unit
Removal Procedure 209
2. Remove the indoor unit.
1
Detach the indoor unit
from the installation
plate.
3. Remove the piping fixture.
1
Release the hook on
the upper side of the
piping fixture on the
back of the unit.
4. Remove the heat
exchanger.
1
Widen the auxiliary
piping to the extent of
10°~20°.
At an angle of 10°~20°
Step
Procedure Points
