Troubleshooting SiBE04-101
96 Service Diagnosis
4.9 Faulty Indoor Unit PCB
Remote Controller
Display
∗
Indoor unit LED
Display
Method of
Malfunction
Detection
The condition of the transmission circuit for indoor-outdoor signal transmission is detected.
Malfunction
Decision
Conditions
When the transmission circuit remains ON.
Supposed Causes Faulty indoor unit PCB
Troubleshooting
Turn on the power again.
Replace the indoor unit PCB(2).
Replace the indoor unit PCB(1).
Are 5V and 12V
outputted at the indoor
unit PCB (1) ?
(R1173)
NO
YES
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
