General Functions SiBE04-101
28 Main Function
1.8 Fan Speed Control for Outdoor Units
Outline DC motor is adopted for the outdoor fan, the rotating speed is controlled depending on the condition. In
outdoor unit silent operation, the rotating speed is changed further.
Details of the
Action
Cooling Operation
The fan tap is set as follows:
Heating Operation
50 Class 60 Class 71 Class
HH 770 rpm 760 rpm 820 rpm
H 740 rpm 730 rpm 790 rpm
L 580 rpm 580 rpm 650 rpm
LL 280 rpm 320 rpm 320 rpm
LLL 200 rpm 200 rpm 200 rpm
50 Class 60 Class 71 Class
H 680 rpm 730 rpm 730 rpm
L 530 rpm 550 rpm 580 rpm
(R1165)
Outdoor temperature
46˚C
43˚C
38˚C
21˚C
10˚C
0˚C
-11˚C
HH
H
L
LL
LLL
HH
H
L
LL
LLL
Normal Operation
Inverter stop, fan stop
Outdoor Unit Silent Operation
(R1166)
Outdoor temperature
18˚C
-15˚C
L
H
H
L
H
Normal Operation Outdoor Unit Silent Operation
