Instruction SiBE04-101
68 System Configuration
8
ATTENTION
O
N
O
F
F
Receiver
Preparation Before Operation
■■
■■
■ Setting the batteries
+
–
–
+
Position + and
– correctly!
2
3
1
About batteries
● Always replace two batteries at the same
time. Replace them with new ones of an
identical type.
● Do not use manganese dry batteries since
their use may cause a malfunction.
● If you are not going to use the air
conditioner for a long period, take out all
the batteries.
● Batteries should last for about a year
under normal conditions. When you find
the displays unclear and signal
communication often failing, replace them
with new ones.
● Batteries may be exhausted even before
the recommended date of consumption
printed on them, if the air conditioner was
manufactured many months ago.
● Never try to recharge the batteries.
ATTENTION
■■
■■
■ Operating the remote controller
●
To use the remote controller, aim the transmitter at
the indoor unit. If there is anything to block signals
between the unit and the remote controller, such as
a curtain, the unit will not operate.
●
Do not drop the remote controller. Do not get it wet.
●
The maximum distance for communication is about
7 m.
About the remote controller
● Never expose the remote controller to
direct sunlight.
● Dust on the signal transmitter or receiver
will reduce the sensitivity. Wipe off dust
with soft cloth.
● Signal communication may be disabled if
an electronic-starter-type fluorescent lamp
(such as inverter-type lamps) is in the
room. Consult the shop if that is the case.
● If the remote control signals happen to
operate another appliance, move that
appliance to somewhere else, or consult
the shop.
●
To remove, pull it upwards.
Remote
controller
holder
Set.
■■
■■
■ To fix the remote controller
holder on the wall
Choose a place from where the signals reach
the unit.
Fix the holder to a wall, a pillar, etc. with the
screws supplied with the holder.
Place the remote control in the remote con-
trol holder.
1
2
3
Remote controller
Press with a finger and slide the front
cover to take it off.
Set two alkaline dry batteries (LR03).
Set the front cover as before.
● This will cause the figures on the display
to flash. Set the cloc
k at this point.
1
2
3
SiBE04-101.book Page 68 Monday, October 15, 2001 3:08 PM
