General Functions SiBE04-101
32 Main Function
1.11 Inverter Powerful Operation
Outline In order to exploit the cooling and heating capacity to full extent, operate the air conditioner by increasing
the indoor fan rotating speed and the compressor frequency.
Details of the
Control
When the powerful operation switch is pressed in each operation mode, the fan rotating speed and set
temperature become as follows for 20 min.
Ex.) Powerful operation in cooling mode
Operation Mode Fan rotating speed Target set temperature
Cooling H tap + 80rpm 18˚C
Dry Dry rotating speed + 80-120rpm Normally, target temperature in dry
operation - Approx. 2˚C
Heating H tap + 80rpm 30˚C
Fan (Cooling Only
Type)
H tap + 80rpm —
Automatic (Heat
Pump Type)
Same as cooling/heating powerful
operation
Target is not changed.
Cooling
Fan Tap
50 Class
(Wall Mounted
Type)
60 Class
(Wall Mounted
Type)
71 Class
(Wall Mounted
Type)
50 Class
(Floor/Ceiling
Type)
60 Class
(Floor/Ceiling
Type)
LLL (W1) 350 350 350 300 300
LL (W2) 650 650 650 400 400 ← Thermostat
off is LL
L (W3C) 1020 1100 1100 1020 1100
ML (W4C) 1090 1170 1180 1090 1170
M (W5C) 1170 1240 1270 1170 1240
MH (W6C) 1240 1310 1360 1240 1310
H (W7) 1320 1380 1450 1320 1380
Poweerful 1400 1460 1530 1400 1460
Heating
Fan Tap
50 Class
Heating
60 Class
Heating
71 Class
Heating
50 Class
(Floor/Ceiling
Type)
60 Class
(Floor/Ceiling
Type)
LLL (W1) 350 350 350 300 300 ← Thermostat
off is LLL
LL (W2) 650 650 650 400 400
L (W3W) 960 1000 1000 860 940
ML (W4W) 1040 1090 1110 960 1030
M (W5W) 1120 1190 1220 1060 1130
MH (W6W) 1200 1280 1330 1160 1220
H (W8) 1280 1380 1450 1260 1320
Poweerful 1360 1460 1530 1340 1400
(R1167)
Target temp.
Fan
80rpm
Set temp.
18˚C
Powerful ON
Powerful OFF
H tap
Set tap
It should be the lower limit of cooling temperature.
It counts 20 min. also in the remote controller.
Ending condition: "or" in 1 to 3
1. TPF ends.
2. Stop
3. Powerful operation is OFF.
20min.
SiBE04-101.book Page 32 Monday, October 15, 2001 3:08 PM
