SiBE04-101 Specifications
Specifications 5
230V, 50Hz
Notes: MAX. interunit piping length: 30m
MAX. interunit height difference: 20m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
The Fan Control of the Outdoor Unit on the Outdoor Conditions Less than 10˚C (In Cool Operation)
Models
Indoor Units FTXD71JV1B
Outdoor Units
RXD71JV1B
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 7.1 (0.9~8.0) 8.5 (0.9~9.5)
Btu/h 24,300 (3,100~27,300) 29,100 (3,100~32,500)
kcal/h 6,100 (775~6,880) 7,310 (775~8,170)
Moisture Removal L/h 4.5 —
Running Current (Rated) A 11.5 12.0
Power Consumption Rated
(Min.~Max.)
W 2,630 (450~3,450) 2,740 (450~3,800)
Power Factor % 99.4 99.3
COP W/W 2.70 3.10
Piping
Connections
Liquid mm φ9.5
Gas mm φ15.9
Drain mm φ18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Units FTXD71JV1B
Front Panel Color Almond White
Air Flow Rate
m³/min
(cfm)
H 13.7 (484) 17.3 (611)
M 11.8 (417) 14.1 (498)
L 9.9 (349) 11.1 (392)
Fan
Type Cross Flow Fan
Motor Output W 54
Speed Steps 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.22 0.22
Power Consumption (Rated) W 50 50
Power Factor % 98.8 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 298×1,050×190
Packaged Dimensions (W×D×H) mm 1,183×367×289
Weight kg 12
Gross Weight kg 16
Operation
Sound
H/M/L dBA 46/42/37 46/40/34
Outdoor Units RXD71JV1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63ZXD
Motor Output W 1,900
Refrigerant
Oil
Model SUNISO 4GSD.I.
Charge L 0.65
Refrigerant
Model R22
Charge kg 1.70
Air Flow Rate
(H/L)
m³/min 51.5/41.5 45.6/35.6
cfm 1,818/1,465 1,610/1,257
Fan
Type Propeller
Motor Output W 53
Running Current (Rated) A 11.28 11.78
Power Consumption (Rated) W 2,580 2,690
Power Factor % 99.4 99.3
Starting Current A 12.0
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (W×D×H) mm 929×359×784
Weight kg 53
Gross Weight kg 57
Operation Sound dBA 52 52
Drawing No. 3D029185
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27˚CDB/19˚CWB
Outdoor ; 35˚CDB/24˚CWB
Indoor ; 20˚CDB
Outdoor ; 7˚CDB/6˚CWB
7.5m
RXD50JV1B RXD60JV1B RXD71JV1B
Fan Motor Rotation Speed (rpm) LL 280 320 320
LLL 200 200 200
Air Flow Rate (m³/min) LL 17.0 19.0 19.0
LLL 11.0 11.0 11.0
The Outdoor Temperature (˚C) LL 0˚C~10˚C 0˚C~10˚C 0˚C~10˚C
LLL Less than 0˚C Less than 0˚C Less than 0˚C
SiBE04-101.book Page 5 Monday, October 15, 2001 3:08 PM
