Instruction SiBE04-101
56 System Configuration
1
2
POWERFUL operation quickly maximizes the
cooling (heating) effect in any operation mode.
You can get the maximum capacity with a touch
of a button.
● Pressing the (POWERFUL) button during
operation starts POWERFUL operation.
● POWERFUL operation ends in 20 minutes.
Then the system automatically operates again
with the settings which were used before
POWERFUL operation.
● During you use “POWERFUL operation”, the
other functions will not go on.
Press .
■■
■■
■ To cancel POWERFUL operation:
POWERFUL
Operation
1
OUTDOOR UNIT
SILENT Operation
Display
Press .
Notes on POWERFUL operation
● In COOL and HEAT mode
To maximize the cooling and heating effect, the
capacity of outdoor unit must be increased and
the air flow rate be fixed to the maximum
setting.
The temperature and air flow settings are not
variable.
● In DRY mode
The temperature setting is lowered by 3˚C and
the air flow rate is slightly increased.
OUTDOOR UNIT SILENT operation lowers the
noise-level of the outdoor unit by changing the
frequency and fan rpm on the outdoor unit.
This function is convenient when sleeping, etc.
How to use OUTDOOR UNIT SILENT operation
∗ This function is available in COOL, HEAT,
and AUTO modes.
∗ This function is not available when it is
connected to Multi system.
■■
■■
■ To use the “OUTDOOR UNIT
SILENT operation”
Press
SILENT
.
■■
■■
■ To cancel the “OUTDOOR UNIT
SILENT operation”
Press
SILENT
again.
Note on OUTDOOR UNIT SILENT operation
● This function is available in COOL, HEAT,
and AUTO modes.
(This is not available in DRY mode.)
● Using POWERFUL operation (P12) during
OUTDOOR UNIT SILENT operation will
disengage OUTDOOR UNIT SILENT
operation.
● Turning the unit off either with the remote
control or by flipping the switch on the unit
during OUTDOOR UNIT SILENT operation
will shut the unit off. The unit will continue in
OUTDOOR UNIT SILENT operation when
turned bac
k on.
SiBE04-101.book Page 56 Monday, October 15, 2001 3:08 PM
