![Daikin EKHWMX300CA [50/68] Error codes](/views2/1788393/page50/bg32.png)
8 x Errors, malfunctions and messages
Installation and maintenance instructions
50
Daikin Altherma M ECH
2
O
Solar storage tank with heating controller
008.1446799_00 – 07/2019 – EN
8.3 Error codes
In the case of all malfunctions / error messages due to possible defective sensors, always check all accompanying connec-
tion cables, connecting points (plug contacts seated correctly) and printed circuit boards before exchanging them.
Component assignment: see fig. 3-1 to fig. 3-3 and fig. 8-4
Code Malfunction /
error message
Component/
Designation
Causes and possible fault elimination
Display Internal
E75 —
Fault feed flow
sensor
Feed temperature sen-
sor t
V, BH
Feed temperature sensor defective.
● Check, replace.
E76 —
Storage tank tem-
perature sensor
fault
Storage tank tempera-
ture sensor t
DHW
Storage tank temperature sensor t
DHW
or connecting cable defec-
tive or not connected.
● Check, replace.
● Check [Storage Config] setting.
E81 —
Communication
fault
Circuit
boardRoCon BM2C
Parameter storage in the EEPROM disturbed.
● Contact a Daikin service technician.
E88 —
Circuit
boardRoCon BM2C
Parameter storage in the external flash memory disturbed.
● Contact a Daikin service technician.
E91 —
Connected CAN mod-
ules
CAN module bus ID duplicated, set unique data bus address.
E128 —
Fault T-return
Return flow temperature
sensor t
R
(outdoor unit)
Return flow temperature sensor t
R
connecting cable defective.
● Check, replace.
E129 —
Fault pressure
sensor
Pressure sensor P
hyd
Pressure sensor P
hyd
defective.
● Check, replace.
E198 —
Flow measure-
ment not plausible
Flow sensor FLS (out-
door unit),
3-way switch
valve3UVB1
Error occurs when 3-way switch valve 3UVB1 is in bypass position,
the internal circulation pump is running but a volumetric flow that is
too low is measured.
Required minimum water flow rate:
5-7 kW 11-16 kW
"Heating" operating mode 480 l/h
600 l/h
"Cooling" operating mode 600 l/h 900 l/h
Automatic defrost function active 780 l/h 900 l/h
– Air in heating system.
● Vent.
– Internal circulation pump is not running.
● Check electrical connection and controller settings. If circu-
lation pump is defective, replace it.
– Flow sensor FLS dirty, clogged.
● Check, clean.
– Flow sensor FLS defective.
– 3-way switch valve 3UVB1 valve drive defective.
● Check, replace.
E200 —
Communication
fault
Electrical components
Communication between RoCon BM2C and printed circuit board
A1P is disturbed.
– Outdoor unit is not connected
– Wiring or connections, poor contact.
● Check, replace
E8005 —
Water pressure in
heating system too
low
Pressure sensor P
hyd
Water pressure has fallen below permissible minimum value.
– Insufficient water in the heating system.
● Check heating system for leaks, top up water.
– Pressure sensor P
hyd
defective.
● Check, replace.
E8100 — Communication Electrical components
Initialisation after heat pump start failed.
Printed circuit board A1P (outdoor unit) defective.
● Check, replace.
