8 x Errors, malfunctions and messages
Daikin Altherma M ECH
2
O
Solar storage tank with heating controller
008.1446799_00 – 07/2019 – EN
Installation and maintenance instructions
51
E9000 —
Temporary internal
message
—
Not relevant for proper system operation.
E9001 80 Fault T-return
Return flow temperature
sensor t
R2
Sensor or connecting cable defective.
● Check, replace.
E9002 81
Fault feed flow
sensor
Feed temperature sen-
sor t
V1
or t
V, BH
Sensor or connecting cable defective.
● Check, replace.
E9003 89 Fault frost protec
Plate heat exchanger
(PWT)
Measured value t
V1
< 0°C
– Failure of the frost protection function for the plate heat
exchanger because the water flow is too low. See fault code
E9004 / 7H.
– Failure of the frost protection function for the plate heat
exchanger because there is a lack of refrigerant in the system.
See fault code E9015 / E4.
E9004 7H Fault volume flow FlowSensorFLS
Water flow is too low or non-existent. Required minimum water flow
rate:
5-7 kW 11-16 kW
"Heating" operating mode 480 l/h
600 l/h
"Cooling" operating mode 600 l/h 900 l/h
Automatic defrost function active 780 l/h 900 l/h
Check the following items:
● All stop valves of the water circuit must be completely open.
● Optional water filters must not be contaminated.
● Heating system must run within its operating range.
● Heating system and internal circulation pump must be
completely vented.
● On the controller (rotary switch position "Info"
), check
whether sufficient water pressure (> 0.5 bar) is available; if
necessary, top up heating water.
● Check function of the 3-way switch valve 3UVB1 (compare
actual position of 3UVB1 with indicated position BPV in
parameter [Overview]).
● Does this fault occur during defrosting in room heating or hot
water preparation operating mode? With optional backup heater:
check its power supply and fuses.
● Check fuses (pump fuse (FU1) on printed circuit board A1P
(outdoor unit) and conductor plate fuse (F1) on RoCon BM2C
printed circuit board).
● Check flow sensor FLS (outdoor unit) for soiling and function; if
necessary, clean, replace.
● Frost damage on the plate heat exchanger (outdoor unit)
E9005 8F
Feed temperature
t
V, BH
> 75 °C
Feed temperature sen-
sor t
V, BH
Feed temperature of backup heater (t
V, BH
) is too high.
– Feed temperature sensor delivers incorrect values. Temperature
sensor or connecting cable defective.
● Check, replace.
E9006 8H
Feed temperature
t
V, BH
> 65 °C
Feed temperature sen-
sor t
V, BH
E9007 A1 IU main board def
Printed circuit board A1P
(outdoor unit)
Communication between heat pump outdoor unit and internal unit
disturbed.
– Electromagnetic influences.
● Perform reset.
– Printed circuit board A1P defective.
● Replace printed circuit board A1P.
– EEPROM read error
E9008 A5
Coolant tempera-
ture
Temperature sensor
(refrigerant fluid side) t
L2
Refrigerant temperature outside of the valid range
No heat consumption at the plate heat exchanger.
● Check flow rate.
● If flow rate is OK, replace refrigerant temperature sensor.
Code Malfunction /
error message
Component/
Designation
Causes and possible fault elimination
Display Internal
