8 x Errors, malfunctions and messages
Installation and maintenance instructions
56
Daikin Altherma M ECH
2
O
Solar storage tank with heating controller
008.1446799_00 – 07/2019 – EN
E9048 EA 4-way valve 4-way valve
The following condition occurs for 10 min after operation for 5 min:
Heating: temperature of the condenser negative outlet water tem-
perature < -10 °C
● Check the thermistor for the outlet water in the heat exchanger.
● Check the thermistor for the refrigerant fluid side.
● Check whether the current flow LED flashes at regular intervals.
● Check whether the correct replacement part has been installed.
● Check whether the outer main conductor plate is receiving a
power supply.
● Check the 4-way valve's coil/wiring harness.
● Check the 4-way valve's body.
● Check for insufficient refrigerant. Perform a leak test.
● Check the quality of the refrigerant.
● Check the shut-off valves.
● Check whether the hydro printed circuit board is being supplied
with voltage.
E9049 F6
high pressure cool-
ing
Temperature sensor on
the evaporator
The temperature measured by the temperature sensor on the fin
heat exchanger exceeds 60
°C
● Check whether the installation room meets the regulations.
● Check the fan.
● Check the fan motor's connection and wiring.
● Check the expansion valve.
● Check the outer inverter conductor plate.
● Check whether the current flow LED flashes at regular intervals.
● Check whether the correct replacement part has been installed.
● Check whether the outer main conductor plate is receiving a
power supply.
● Check the shut-off valves.
● Check the heat exchanger.
● Check the temperature sensor on the fin heat exchanger.
● Check the quality of the refrigerant.
E9050 H0 Comfort Heating Software
Power supply condition malfunction detected before or directly after
the compressor starts up
● Check the compressor.
● Check the compressor's connection and wiring.
● Check the operation of the expansion valve (fluid return flow).
● Check the refrigerant filling capacity, and check for leaks.
● Check the outer inverter conductor plate.
● Check whether the current flow LED flashes at regular intervals.
● Check whether the correct replacement part has been installed.
● Check whether the outer main conductor plate is receiving a
power supply.
E9052 H8
compressor start-
up
Software
Compressor operating frequency below 55 Hz, voltage below 0.1 V
and input current below 0.5
A
● Check the compressor.
● Check the compressor's connection and wiring.
● Check the operation of the expansion valve (fluid return flow).
● Check the refrigerant filling capacity, and check for leaks.
● Check whether the power supply meets the regulations. Check
for frequency fluctuations.
● Check the outer inverter conductor plate.
● Check whether the current flow LED flashes at regular intervals.
● Check whether the correct replacement part has been installed.
Code Malfunction /
error message
Component/
Designation
Causes and possible fault elimination
