10 x Technical data
Installation and maintenance instructions
62
Daikin Altherma M ECH
2
O
Solar storage tank with heating controller
008.1446799_00 – 07/2019 – EN
10.1.2 EKHWMX(B)500C
Type EKHWMX
500C B500C
Can be used with Exterior heat pump unit
EBLQ
05C2V3
EBLQ
07C2V3
EBLQ
05C2V3
EBLQ
07C2V3
Dimensions and weights Unit
Dimensions (H x W x D) cm 189,6 x 79 x 79
Empty weight kg 85
91
Storage tank
Total storage capacity litres 477
Maximum permissible storage water temperature °C 85
Heat consumption at stand-by and at 60 °C kWh/24h 1,4
Drinking water heat
exchanger (stainless
steel 1.4404)
Water capacity heat exchanger litres 28,2 28,1
Maximum operating pressure bar 6 6
Domestic water heat exchanger sur-
face
m
2
5,9 5,8
Storage tank charg-
ing heat exchanger
(stainless steel
1.4404)
Water capacity heat exchanger litres 11,9 12,1
Heat exchanger surface area m
2
2,4 2,4
Pressurised solar
heat exchanger
(stainless steel
1.4404)
Water capacity heat exchanger litres — 10,1
Heat exchanger surface area m
2
— 1,6
Pipe connections
Cold and hot water inches 1" outer thread
Heating feed and return flow inches 1" outer thread
Solar connections
inches 1" outer thread
inches — 3/4" IG + 1" AG
Operating data
Operating range
Feed temperature
for room heat-
ing/cooling function
Heating
(min./max.)
°C
15 to 55
Cooling
(min/max)
°C 5 to 22
Hot water prepara-
tion (with EKBUxx)
Heating
(min./max.)
°C 25 to 80
Noise level
Audibility dBA 40
Sound pressure
1)
dBA 28
Electrical data
Voltage supply
Phases — 1
Voltage V 230
Voltage range V Voltage ±10%
Frequency Hz 50
Mains connection
2)
Heat pump outdoor unit — 3G
Optional auxiliary
heating
Backup heater
(EKBUxx)
— 3G (1-phase) / 5G (3-phase)
1) At a reference clearance of 1 m.
2) Number of individual lines in the connection cable including protective earth conductor. The cross-section of the individual lines is dependent
on the current load, the length of the connection cable and the respective legal provisions.
Tab. 10-2 EKHWMX(B)500C basic data
