Daikin EKHWMX500CA [60/68] X hydraulic system connection
![Daikin EKHWMXB300CA [60/68] X hydraulic system connection](/views2/1788393/page60/bg3c.png)
Short name Meaning
1 Cold water distribution network
2 Hot water distribution network
3 Heating flow
4 Heating return flow
5 Mixer circuit (optional)
6 Circulation (optional)
7 Check valve, return valve
7a Non-return valves
8 Solar circuit
9 Gas pipe (refrigerant)
10 Fluid pipe (refrigerant)
3UVB1
3-way switch valve (internal heat generator cir-
cuit)
3UV DHW 3-way switch valve (hot water / heating)
EKBUxx Backup heater
C Refrigerant compressor
CW Cold water
DHW Domestic hot water
E Expansion valve
FLS
FlowSensor - solar throughput and inflow tem-
perature measurement
H
1,
H
2
… H
m
Heating circuits
MAG Diaphragm expansion vessel
MIX 3-way-mixer with drive motor
MK1 Mixer group with high-efficiency pump
MK2
Mixer group with high-efficiency pump (PWM-
regulated)
P
Mi
Mixing circuit pump
P
S
Solar operating pump +
P
Z
Circulation pump
PWT Panel heat exchanger (condenser)
RoCon mb Controller for Daikin Altherma M ECH
2
O
EHS157068 Mixer circuit control
EKSRPS4A Solar control and pump unit
SAS1 Sludge and magnetic separator
SK Solar panel field
SV Safety overpressure valve
t
AU
Outside temperature sensor (optional)
t
DHW
Storage tank temperature sensor (heat genera-
tor)
t
Mi
Inflow temperature sensor, mixer circuit
t
K
Solar collector temperature sensor
t
R
Solar return flow temperature sensor
T
V
Solar flow temperature sensor
V Fan (vaporiser)
VS Scalding protection VTA32
Tab. 9-1 Abbreviations on hydraulics plans
9 x Hydraulic system connection
Installation and maintenance instructions
60
Daikin Altherma M ECH
2
O
Solar storage tank with heating controller
008.1446799_00 – 07/2019 – EN
