![Nissan Note [12/34] Service data and specifications sds](/views2/1789813/page12/bgc.png)
FL-12
[CR]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
PFP:00030
Standard and Limit
BBS003YM
Tightening Torque
BBS003YN
Unit: N·m (kg-m, ft-lb)
Fuel tank capacity
Approx. 46 (10-1/8 Imp gal)
Fuel tank mounting band 21.0 - 29.0 (2.1 - 3.0, 15 - 21)
Fuel filler tube 15.8 - 24.2 (1.7 - 2.4, 12 - 17)
Lock ring 65.0 - 75.0 (6. - 7.7, 48 - 55)
