FL-2
[CR]
PREPARATION
[CR]
PREPARATION PFP:00002
Special Service Tools
BBS003YH
Tool number
(RENAULT tool number)
Tool name
Description
KV993G0010
(Mot. 1397)
Lock ring wrench
Removing and Installing lock ring
PBIC1627E
