FUEL FILTER
FL-27
[K9K]
C
D
E
F
G
H
I
J
K
L
M
A
FL
DRAINING WATER (LHD)
Refer to EM-227, "PRECAUTIONS" , EC-1625, "WATER DRAINING" .
1. Remove right fender protector. Refer to EI-14, "
FENDER PROTECTOR" .
2. Remove foam insulator.
3. Open drain valve at the bottom of fuel filter.
CAUTION:
Put a shop cloth under the drain valve, to avoid the water and fuel spill on ABS actuator.
FUEL FILTER CHECK
Check fuel filter for fuel leakage, damage and other abnormal signs.
Changing Fuel Filter
BBS003YZ
REMOVAL (RHD)
1. Remove quick connectors in the following procedures.
● Pinch quick connector square-parts with your fingers, and pull
out the quick connector by hand.
● If quick connector and tube on vehicle are stuck, push and
pull several times until they move, and pull out.
2. Remove fuel filter from fuel filter bracket.
CAUTION:
Do not spill the fuel during removal. If the fuel is spill,
immediately wipe it off. Be especially careful to prevent the
fuel from adhering to the insulators of the engine mounts.
REMOVAL (LHD)
1. Remove priming bulb from priming bulb bracket.
2. Remove fuel filter from fuel filter bracket.
3. Remove quick connectors as above.
CAUTION:
Put a shop cloth under the drain valve, to avoid the water and fuel spill on ABS actuator. Be espe-
cially careful to prevent any damage.
INSTALLATION
Install in the reverse order of removal, paying attention to the following points:
● To install fuel filter connectors, respect paint marks on fuel filter
as shown.
● After installation, operate the priming bulb vertically, if it is possi-
ble, to perform air bleeding.
Refer to FL-28, "
Bleeding Fuel Filter" .
CAUTION:
Do not bend or twist the tube during installation and
removal.
MBIB1048E
MBIB1049E
MBIA0095E
