Nissan Note [28/34] Bleeding fuel filter
![Nissan Note [28/34] Bleeding fuel filter](/views2/1789813/page28/bg1c.png)
FL-28
[K9K]
FUEL FILTER
Bleeding Fuel Filter
BBS003Z0
1. Prime the circuit using the priming bulb.
2. Perform engine cranking with repeating several times until
engine starting.
3. If the engine does not start, use a flat bladed screwdriver to lift
up the button on the fuel return pipe and perform engine crank-
ing.
4. When the bleeding is completed, push the button, and check
absence of leakage.
: Bleeding position
: Normal position
MBIB9045E
MBIB9038E
