FRONT WIPER AND WASHER SYSTEM
WW-29
C
D
E
F
G
H
I
J
L
M
A
B
WW
4. CHECK BCM GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
OK or NG
OK >> GO TO 5.
NG >> Check harness ground circuit.
5. ACTIVE TEST
With CONSULT-ll
1. Turn ignition switch ON.
2. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST”
on “SELECT DIAG MODE” screen.
3. Select “FRONT WIPER” on “SELECT TEST ITEM” screen.
4. Touch “LO” or “HI” screen.
Without CONSULT-ll
Start up auto active test. Refer to PG-22, "
Auto Active Test" .
Does front wiper operate normally?
YES >> GO TO 6.
NO >> GO TO 8.
6. CHECK CIRCUIT BETWEEN COMBINATION SWITCH AND BCM
With CONSULT-ll
1. Select “BCM” on CONSULT-II, and select “WIPER” on “SELECT
TEST ITEM” screen.
2. Select “DATA MONITOR” on “SELECT DIAG MODE” screen.
Make sure that “FR WIPER INT”, “FR WIPER LOW”, and “FR
WIPER HI” turn ON-OFF according to wiper switch operation.
Without CONSULT-ll
Refer to LT-125, "
Combination Switch Inspection" .
OK or NG
OK >> GO TO 7.
NG >> Check combination switch (wiper switch). Refer to LT-
125, "Combination Switch Inspection" .
7. CHECK CIRCUIT BETWEEN IPDM E/R AND BCM
Select “BCM” on CONSULT-II, and perform self-diagnosis for
“BCM”.
Displayed self
-diagnosis results
NO DTC>>Replace BCM. Refer to BCS-17, "Removal and Installa-
tion of BCM" .
CAN COMM CIRCUIT>>Check CAN communication line of BCM.
Refer to BCS-17, "
CAN Communication Inspection With
CONSULT-II (Self-Diagnosis)" .
Connector Terminal
Ground
Continuity
M57 2
Yes
M59 70
MKIB0353E
SKIA3486E
PKIB0110E
PKIA7627E
