![Nissan Note [73/92] System description](/views2/1789835/page73/bg49.png)
HEADLAMP WASHER
WW-73
C
D
E
F
G
H
I
J
L
M
A
B
WW
HEADLAMP WASHER PFP:28620
Components Parts and Harness Connector Location
BKS001M3
System Description
BKS0013F
Headlamp washer operates under the following conditions.
● When lighting switch is in 1ST position
● When daytime light system is operating
● When auto light system is operating (low beam is ON)
When the headlamp washer switch is ON position the BCM (body control module) receives input signal
requesting the headlamp washer operates. The CPU (central processing unit) of the IPDM E/R (intelligent
power distribution module engine room) controls the headlamp washer relay coil. When activated this relay
directs power headlamp washer motor.
OUTLINE
Power is supplied at all times
● through 30A fusible link (letter L, located in fuse and fusible link box).
● to headlamp washer relay terminals 1 and 3.
● through 40A fusible link (letter J, located in fuse and fusible link box).
● to BCM terminals 74 and 79.
● through 20A fuse (No.61, 62, located in IPDM E/R).
● to IPDM E/R (CPU).
When ignition switch ON or START position, power is supplied
● to IPDM E/R (CPU), and
● through10Afuse[No.5,locatedinfuseblock(J/B)]
● to BCM terminal 24.
Ground is supplied
● to IPDM E/R terminals 3 and 54, and
● to head lamp washer motor terminal 1,
● through body grounds E28, E44 and E45.
: Vehicle front
1. IPDM E/R E10, E11, E12
[Engine room (left)]
2. BCM M57, M58, M59
(View with instrument panel removed)
3. Data link connector
4. Headlamp washer switch M18
(RHD models)
5. Headlamp washer motor E25
(View with front bumper removed)
MKIB2265E
