Nissan Note — руководство по проверке значений для системы BCM [80/92]
![Nissan Note [80/92] Turn wiper dial position to 4 except when checking waveform or voltage of wiper dial position wiper dial position can be confirmed on consult ii refer to ww 24 data monitor](/views2/1789835/page80/bg50.png)
WW-80
HEADLAMP WASHER
Reference Values for BCM (Input)
BKS001KQ
CAUTION:
● Check combination switch system terminal waveform under the loaded condition with lighting
switch, turn signal switch and wiper switch OFF not to be fluctuated by overloaded.
● Turn wiper dial position to 4 except when checking waveform or voltage of wiper dial position.
Wiper dial position can be confirmed on CONSULT-II. Refer to WW-24, "
DATA MONITOR" .
34 Y
Combination switch
input 4
Input ON
● OFF
● Front fog lamp switch ON
● Lighting switch 2ND
● Lighting switch PASSING
(Operates only PASSING switch)
● Turn signal switch to left
WW-80, "
Reference Values for
BCM (Input)"
39 Y CAN L
Input/
output
—— —
62 G
Headlamp washer
switch
Input ON
Headlamp
washer switch
Operated 0
Other than above Battery voltage
70 B Ground — ON — 0
74 Y
Power source
(Fusible link)
Input OFF — Battery voltage
79 Y
Power source
(Fusible link)
Input OFF — Battery voltage
Ter-
minal
No.
Wire
color
Signal name
Signal
input/
output
Measuring condition
Reference value [V]
Igni-
tion
switch
Operation or condition
INPUT Condition and reference value
INPUT 5
(Wiper intermit-
tent dial position
4)
OFF
Approx. 0.9V
Lighting switch 1ST
Approx. 1.5 - 2.0V
Lighting switch 2ND
Approx. 2.5 - 3.0V
Lighting switch HI beam
(Operates only HI beam switch)
Approx. 1.5 - 2.0V
Turn signal switch to right
Approx. 1.5 - 2.0V
—
PKIB4956J PKIB8624J PKIB8639J
PKIB8644J
PKIB8625J
