HEADLAMP WASHER
WW-81
C
D
E
F
G
H
I
J
L
M
A
B
WW
INPUT 4
(Wiper intermit-
tent dial position
4)
OFF
Approx. 1.0V
Lighting switch 2ND
Approx. 1.5 - 2.0V
Turn signal switch to left
Approx. 2.0V
Front fog lamp switch
(Operates only front fog lamp
switch)
Approx. 1.5 - 2.0V
Lighting switch PASSING
(Operates only PASSING switch)
Approx. 2.0V
—
INPUT 3
(Wiper intermit-
tent dial position
4)
OFF
Approx. 1.0V
Lighting switch AUTO
Approx. 2.0V
Front wiper switch INT
Approx. 2.0V
Any of several conditions below
●Front wiper switch LO
●Front wiper switch MIST
Approx. 2.0V
Rear fog lamp switch
Approx. 1.5V
—
INPUT Condition and reference value
PKIB4958J PKIB8628J PKIB8630J
PKIB8627J
PKIB8629J
PKIB4958J PKIB8631J PKIB8632J
PKIB8629J
PKIC1030E
