Bomann DBC 776 CB [30/50] Instructions
30
14 MAX mark for water level
15 Ceramic sole plate
Instructions
Unpacking
1. Remove any protective foils and stickers from the soleplate.
2. Please unwind the lead completely.
Set up / assemble the stand (8)
Use the supplied stand for resting the iron securely on it.
A screw clamp is integrated onto the underside of the stand.
Use this to secure the stand to your ironing board or to a table.
1. Pull the screw clamp out of the clamp socket and fold out
through 180°. Push the screw clamp rmly into the other
clamp socket until it clicks into place.
2. Set the stand onto your work surface. Turn the screw
clockwise.
3. To disassemble the stand, loosen the screw by turning anti-
clockwise. Stow the screw clamp back into the recess on
the bottom of the stand. Push it into the clamp socket until it
clicks into place.
Function switch (7) on the stand
Switch setting Symbol Function
To p Ironing without cord
Middle Lock the iron to the stand
Bottom Ironing with cord
Electrical connection
• Make sure that the iron voltage (see name plate) and the
line voltage match.
• The mains plug should only be inserted into a correctly
installed 230 V ~ 50 Hz socket with earthing contact.
Connected Wattage
The station has a total maximum wattage of 2000 W. With this
connected load a separate supply line protected by a 16 A
household circuit breaker is recommended.
CAUTION: OVERLOAD!
• If you use extension leads, these should have a cable
cross-section of at least 1.5 mm².
• Do not use any multiple sockets, as this device is too
powerful.
Temperature Control on the Iron (12)
The symbols on the control correspond to the following settings:
MIN off
●
Synthetics, nylon, acrylic,
rayon
low temperature
● ● Wool, silk medium temperature
● ● ● Cotton, linen high temperature
MAX
maximum temperature
Water
Please use only distilled water.
Do not ll battery water, water from the clothes dryer and water
containing additives (such as starch, perfume, softener or other
chemicals) into the water reservoir.
This could damage the iron due to residues forming in the
steam chamber. These residues may cause impurities to the
fabric when dropping out of the holes in the soleplate.
Water Tank (13)
The tank volume is 220 ml.
1. Set the steam volume regulator (3) to the “ “ position (no
steam).
2. Set the iron onto the stand or hold it horizontally.
3. Check the MAX mark (14).
4. Fill the water reservoir at the rell opening (2). Close the lid
of the tank.
Operation
NOTE:
Always set the temperature control to “MIN” before connect-
ing the appliance to a power point, or before disconnecting it.
Before Initial Use
• Clean the ironing base with a slightly damp cloth.
• In order to remove all residues before initial use, please
pass the iron a few times over an old clean cloth.
Ironing without cord ( )
You can iron without the cord with or without steam.
The preset temperature is maintained for around 50 seconds
when ironing without the cord. If you want to continue ironing at
this temperature, the iron must be heated up again. To do so,
place it back onto the stand.
Ironing without steam
NOTE:
Sort out the garments according to their ironing temperatures.
1. Set the steam volume regulator (3) to the “ “ position (no
steam).
2. Rest the appliance on the stand or stand upright.
3. Only connect the machine to a properly installed safety
socket, 230 V~, 50 Hz.
