ITEM

NO.

PART NAME Q’TY

1 FRONT CAP 1

2 GRIP 1

3 STOPPER RING 1

4 NEEDLE HOLDER 1

5 RETAINER SPRING 1

6 SPRING HOLDER (A) 1

7 SEAL LOCK HEX. SOCKET HD. BOLT M6×25 4

8 FRONT COVER 1

9 O-RING (1AS-60) 1

10 OIL SEAL 1

11 RUBBER RING 1

12 URETHANE RING HOLDER 1

13 COAXIAL RETAINER D35 1

14 BALL BEARING 6007DDUAV2S 1

15 BEARING WASHER 1

16 NEEDLE ROLLER D8×20 2

17 RETAINER SLEEVE 1

18 NEEDLE PIN D6×64

19 O-RING (C) 1

20 SECOND HAMMER 1

21 DAMPER WASHER 1

22 DAMPER 1

23 DAMPER HOLDER 1

24 STRIKER 1

25 O-RING 2

26 CYLINDER 1

27 LOCK SPRING 1

28 SPRING HOLDER (B) 1

29 LOCK SLEEVE 1

30 CLUTCH SPRING 1

31 CLUTCH 1

32 BEVEL GEAR 1

33 PISTON PIN 1

34 PISTON 1

35 CONNECTING ROD 1

36 RETAINING RING FOR D10 SHAFT 1

37 FEATHER KEY 3×3×82

LOCK HEX. SOCKET HD. BOLT (W/FLANGE) M5

39 CRANK COVER 1

40 O-RING 1

41 CRANK SHAFT 1

42 RETAINING RING FOR D40 HOLE 1

43 BALL BEARING 6203DDCMPS2L 1

44 O-RING (S-40) 1

45 OIL SEAL (B) 1

46 CYLINDER CRANK CASE 1

47 SLIP CLUTCH ASS’Y 1

48 BEVEL PINION 1

49 COLLAR 1

50 OIL SEAL (A) 1

51 BALL BEARING 6002DDCMPS2L 1

52 WASHER 1

53 WASHER (A) 1

54 GEAR HOLDER 1

55 SPRING (C) 10

56 NEEDLE 10

57 SECOND GEAR 1

58 SPACER 1

59 BALL BEARING 629VVC2PS2L 1

60 BEARING WASHER (C) 1

61 FIRST GEAR 1

62 NEEDLE BEARING (M661) 1

63 GEAR COVER 1

64 O-RING 1

65 SEAL LOCK HEX. SOCKET HD. BOLT M6×22 2

66 LEAF SPRING 1

67 SPRING BUMPER (A) 1

68 WASHER 1

69 SEAL LOCK HEX. SOCKET HD. BOLT M4×12 2

70 NEEDLE ROLLER 4

ITEM

NO.

PART NAME Q’TY

71 SEAL LOCK HEX. SOCKET HD. BOLT M5×12 1

72 RUBBER SHEET (B) 1

73 WEIGHT (B) 1

74 WEIGHT (A) 1

75 BALL BEARING 6201DDCMPS2L 1

76 DUST WASHER (B) 1

77 FAN 1

78 ARMATURE ASS’Y 1

79 FAN GUIDE 1

80 SIDE HANDLE 1

81 HANDLE HOLDER 1

82 HANDLE BOLT 1

83 STOPPER ROD 1

84 LEVER LABEL 1

85 CHANGE LEVER 1

86 LEVER HOLDER 1

87 RETAINING RING FOR D20 HOLE 1

88 LEVER SHAFT 1

89 O-RING (P-16) 1

90 SEAL LOCK HEX. SOCKET HD. BOLT M6×45 4

91 LEVER SPRING 1

92 PUSHING BUTTON 1

93 PIN D2×10 1

94 RUBBER SHEET (A) 1

95 SPRING BUMPER (B) 1

96 BACK COVER 1

97 BELLOWS 1

98 HEX. SOCKET HD. BOLT (W/FLANGE) M5×35 2

99 NAME PLATE 1

100 TAPPING SCREW (W/FLANGE) D5×20 4

101 HANDLE DAMPER 4

102 TRANSATORY UNIT 1

103 HANDLE (A) 1

104 DISTANCE PIECE (B) 4

105 SEAL LOCK HEX. SOCKET HD. BOLT M5×12 4

106 HOOD 1

107 HANDLE (B) 1

108 TAPPING SCREW (W/FLANGE) D4×25 3

109 HANDLE DAMPER 4

110 HANDLE SHAFT 1

111 HOLDER 1

112 SWITCH (B) 1

113 TAPPING SCREW (W/FLANGE) D4×16 2

114 CORD CLIP 1

115 TERMINAL 1

116 PILLAR TERMINAL 1

117 CORD ARMOR 1

118 CORD 1

119 BRUSH CAP 2

120 CARBON BRUSH 2

121 BRUSH HOLDER 2

122 HEX. SOCKET HD. BOLT (W/FLANGE) M5×12 2

123 HOUSING ASS’Y 1

124 HEX. SOCKET SET SCREW M5×82

125 TAIL COVER 1

126 TAPPING SCREW (W/FLANGE) D5×20 2

127 HEX. HD. TAPPING SCREW D5×55 2

128 STATOR ASS’Y 1

129 BRUSH TERMINAL 2

130 WASHER (A) 1

131 BALL BEARING 608VVC2PS2L 1

132 BEARING HOLDER 1

133 MAGNET 1

134 SPRING BASE 1

135 VINYL TUBE 1

136 CONTROLLER CIRCUIT 1

137 INTERNAL WIRE 1

138 COVER (A) 1

501 CASE (PLASTIC) 1

502

GREASE (A) FOR HAMMER. HAMMER DRILL (30G)

09Back_DH40MRY_EE 10/24/08, 16:5158
