SPECIFICATIONS

APPLICATIONS

1. Drilling various materials

䡬 Drilling metal

Use a metal-working drill bit

䡬 Drilling wood

Use a wood-working drill bit (However, a metal-

working drill bit to make pilot holes for wood

screws or holes smaller than 6.5mm.)

2. Tightening wood screws (Only model FD10VB)

Use the driver bit. Use a Phillips screw for easy

tightening.

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the

power switch is in the ON position, the power tool

will start operating immediately, inviting serious

accident.

3. Extension cord

When the work area is removed from the power

source. Use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

4. Check the tightening of the drill chuck

The drill chuck has been tightened at the factory,

but check again that it is in order before use.

Turn the drill chuck clockwise to tighten.

HOW TO USE

1. Operation of switch

Pulling the trigger of switch and push the stopper,

it keeps, the switched-on condition and it is

convenient for the continuous running. When

switched off, the stopper can be disconnected by

means of pulling the trigger again.

2. Adjustment of speed

[FD10SB]

The maximum speed can be obtained by pulling

the trigger switch.

[FD10VB]

(1) The speed is adjustable from zero to maximum

speed according to the extent the trigger switch is

pulled.

(2) The maximum speed is adjustable from zero to

2800 min

–1

. with the rotation of adjusting knob.

(3) Turn the adjusting knob clockwise for higher speed

and counterclockwise for lower speed. (Rotate the

adjusting knob approximately 1-2/3 turns.) (Fig. 1)

(4) The switch can be locked with the stopper at any

required position irrespective as to how far the

adjusting knob has been rotated. Select a proper

position according to the required speed for each

work.

3. Confirm the direction of bit rotation (Fig. 2)

The bit rotates clockwise (viewed from the rear

side) by pushing the R-side of the reversing switch

lever. The L-side of the lever is pushed to turn the

bit counterclockwise.

CAUTION:

Never change the direction of bit rotation during

operating.

Turn the power switch OFF before changing the

direction of bit rotation.

4. For use as a drill

(1) Mounting drill bit

Tighten drill bit with the chuck wrench. There are

three holes in which the chuck wrench should be

inserted. Tighten them equally in turn at three holes,

without tightening them only at one hole. The drill

bit can be removed in the opposite method as

mentioned above. (Fig. 3)

Model FD10VB FD10SB

Voltage (by areas)* (110V, 115V, 120V, 127V, 220V, 230V, 240V)

Power input 420W*

No load speed 0–2800 min

–1

2800 min

–1

Capacity

Steel 10 mm

Wood 25 mm

Weight (without cord) 1.4 kg

* Be sure to check the nameplate on product as it is subject to change by areas.

PRECAUTIONS ON USING DRILL

1. When mounting the drill bit or driver bit, insert it

fully into the drill chuck and completely tighten the

drill chuck with the chuck wrench.

If mounting is not done properly, it is very dangerous

as the drill bit may slip or loosen during operation.

2. Do not wear gloves made of stuff liable to roll up

such as cotton, wool, cloth or string, etc.

3. Do not touch the bit during or immediately after

operation. The bit becomes very hot during operation

and could cause serious burns.

4. When placing the drill on the floor, make sure that

the drill has stopped completely.

5. Before drilling into a wall, floor or ceiling, thoroughly

confirm that no items such as electric cables or

conduits are buried inside.

6. When working in high position, take care of

downword direction.
