Lenovo Legion 7 16ACHg6 (82N6001LRK) [42/66] Remove the touchpad board cable
![Lenovo Legion 7 16ACHg6 (82N6001LRK) [42/66] Remove the touchpad board cable](/views2/1863208/page42/bg2a.png)
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
CMOS battery
Remove the touchpad board cable
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the solid-state drive (SSD) plate R” on page 30
“Remove the battery pack” on page 32
Step 1. Detach the touchpad board cable connectors and then remove the cable.
Figure 17. Remove the touchpad board cable
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Touchpad board cable
Remove the C cover shield mylar
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the solid-state drive (SSD) plate R” on page 30
“Remove the battery pack” on page 32
Step 1. Remove the C cover shield mylar.
36
Hardware Maintenance Manual
