Lenovo Legion 7 16ACHg6 (82N6001LRK) [61/66] Labels attached to the base cover are country region specific make sure to apply the appropriate labels to the replacement base cover

Appendix A. Label locations

Figure 47. Label layout on the back side of the base cover

Labels attached to the base cover are country/region specific. Make sure to apply the appropriate labels to

the replacement base cover.

Table 6. All base cover labels

Label Label name

Applied country/region

OS label

All

Adapter label All

Country label

KCC label

TW label

Argentina label

Malaysia label

WL/BT label Argentina

Brazil

Israel

South Africa

Indonesia

Morocco

Belarus
