ROUTER
PRM1019P
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europe’s leading suppliers. All
products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive Warranty.
We hope you will enjoy using this product for
many years to come.
For your own safety and for the safety of
others, please read these instructions
carefully before using this appliance. It
will help you understand your product
more easily and avoid unnecessary
risks. Keep this instruction manual in a
safe place for future use.
Introduction
The router has been designed for routing of wood
and wood products. Check the machine, for loose
parts and accessories from transport damage.
Contents
1. Machine specications
2. Safety instructions
3. Assembly
4. Operation
5. Maintenance
1. MACHINE SPECIFICATIONS
Technical specifications
Voltage 220-240 V~
Frequency 50/60 Hz
Power input 2200 W
No load speed 9.000-22.000/min
Cutting depth 70 mm
Collet 6mm, 8mm, 12mm
Weight 5.8 kg
Lpa (sound pressure) 97.8+3 dB(A)
Lwa (sound power) 108.8+3 dB(A)
Vibration left handle 2.232+1.5 m/s2
Vibration right handle 2.384+1.5 m/s2
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
- using the tool for di󰀨erent applications, or with
di󰀨erent or poorly maintainted accessories,
may signicantly increase the exposure level
- the times when the tool is switched o󰀨 or when
it is running but not actually doing the job, may
signicantly reduce the exposure level
Protect yourself against the e󰀨ects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
Product information
Fig. A, B, C, D
1. On/o󰀨 switch
2. Handle
3. Base plate
4. Fixing screws for parallel fence
5. Upper limit knob
6. Spindle lock
7. Collet nut
8. Plunge depth adjustment button
9. Fast-feed button
10. Stopper pole
11. Clamping lever
12. Plunge depth scale
13. Adjusting wheel for electronic speed control
14. Router bit
15. Fixing screw
16. Guide rod
17. Parallel guide
18. Fixing screw
19. Parallel fence
20. Fine adjusting screw
21. Depth stop revolver
22. Screws
23. Template guide
2. SAFETY INSTRUCTIONS
The following symbols are used in these
instructions for use:
Read the instructions carefully.
4
EN
