• To adjust the distance between the bit and the
straight guide, loosen the xing screw (18) and
turn the ne adjusting screw ((20) 1.5 mm
per turn).
• At the desired distance, tighten the Fixing
screws for parallel fence (4) to secure the
straight guide in place.
Mounting the template guide
Fig. D
The template guide is a handy aid for cutting a
pattern.
• Mount the template guide (23) on the router
base (3) using the screws (22).
4. OPERATION
Switching on and o󰀨
Fig. A
• To switch the machine on, press the On/o󰀨
switch (1).
• To switch the machine o󰀨, press the On/o󰀨
switch (1).
Usage tips
• After switching the machine on, make sure the
machine reaches full speed before using it on
the workpiece.
• Clamp the workpiece and make sure that the
workpiece cannot slide from under the
machine during the cutting activities.
• Hold the machine rmly and move it evenly
over the workpiece. Do not force the machine.
• Only use cutters which do not show any signs
of wear. Worn cutters have a negative e󰀨ect
on the e󰀩ciency of the machine.
• Always switch o󰀨 the machine rst before
removing the plug from the wall socket.
Speed Preselection
The required speed can be preselected with the
thumbwheel. Also during running the rotational
speed can be adjusted.
1 – 2 = low speed
3 – 4 = medium speed
5 – 6 = high speed
Max = maximum speed
The required speeds depends on the material and
can be determined by practical testing.
Furthermore router bits with a large diameter
need a lower rotational speed.
Material Diameter
Router bit
Speed stages
Hardwood >20 mm 1 – 2
10 – 20 mm 3 – 4
<10 mm 5 – max
Softwood >20 mm 1 – 3
10 – 20 mm 3 – 6
<10 mm 5 – max
Aluminium >15 mm 1
<15 mm 1 – 2
Plastic >15 mm 1 – 2
<15 mm 2 – 3
Height setting of the router column
Fig. A + E
• The clamping lever (11) is used to set the
maximum height of the router.
• The plunge depth is then xed. This is usually
necessary when using the tool on a special
router table.
• Make sure the router column is not locked.
• The router can be pushed down against the
spring force.
• Lock the router column using the clamping lever
• The router is now locked and will no longer
return to its original position.
Setting the plunge depth
Fig. A + E
The plunge depth can be adjusted by using
buttons 8 and 9. If the plunge depth is set
correctly, the groove in question can be routed
accurately to within 0.1 mm.
• Place the desired cutter in the rool. The router
can be pushed down against the spring force.
• Push the tool down until the cutter touches the
workpiece, then lock it using the clamping lever
• Turn the stopper pole setting nut counterclock-
wise.
• Lower the stopper pole until it makes contact
with the adjusting bolt. The depth of cut is
indicated on the scale by the depth pointer.
• While pressing the fast-feed button, raise the
stopper pole until the desired depth of cut is
obtained. Minute depth adjustments can be
obtained by turning the adjusting knob
(1 mm per turn).
• Now, your predetermined depth of cut can be
obtained by loosening the lock lever and then
lowering the tool body until the stopper pole
6
EN
